Wolf FGB-K-35 - Opening the Casing

3064458_201811
17
Screw
• Undo the central screw at the bottom of the front casing.
• Push in the two locking hooks at the bottom left and right
and pull the casing forwards.
• Lift the front casing upwards to release it and remove it.
9. Opening the casing
