WOLF PRO VENTILATION
105
TOP WIDTH
SUBTRACT 18" (457) FROM OVERALL WIDTH
18" (457)
OVERALL
HEIGHT
OVERALL WIDTH
34" (864)
OVERALL DEPTH
13"
(330)
4" (102)
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
2"
(51)
Pro Island Hoods
10" (254)
OVERALL
HEIGHT
OVERALL WIDTH
4" (102)
22" (559)
OVERALL DEPTH
12"
(305)
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
OVERALL DIMENSIONS
OVERALL WIDTH
4" (102)
24" (610)
OVERALL DEPTH
12"
(305)
18" (457)
OVERALL
HEIGHT
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
OVERALL WIDTH
27" (686)
OVERALL DEPTH
12"
(305)
18" (457)
OVERALL
HEIGHT
2"
(51)
4" (102)
3
/4" (19)
DIAMETER
OF RAIL
Pro 24" (610) Deep Wall Hoods
Pro 27" (686) Deep Wall Hoods
Unit dimensions may vary to ±
1
/ 8 " (3).
Pro Low-Profile Wall Hoods
TOP WIDTH
SUBTRACT 18" (457) FROM OVERALL WIDTH
OVERALL WIDTH
4" (102)
13
1
/2"
(343)
24" (610)
OVERALL DEPTH
18" (457)
OVERALL
HEIGHT
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
Pro Wall Chimney Hoods
Refer to installation
instructions shipped
with each Wolf
product for detailed
specifications.
