WOLF COOKTOP VENTILATION
94
8' TO 9'
(2.4 m – 2.7 m)
FLOOR TO
CEILING HEIGHT
24" TO 30"*
(610 – 762)
TO
COUNTERTOP
21"
(533)
E
4" (102)
6"
(152)
30" OR 35
7
/16"
(762 or 900)
48
1
/2" OR 50
7
/8"
(1232 or 1292)
MAXIMUM
HEIGHT OF HOOD
30
1
/2" OR 32
11
/16"
(775 or 830)
MINIMUM
HEIGHT OF HOOD
*8' (2.4 m) ceilings will not allow for a 30" (762) maximum height above the countertop. Based on a 36" (914) high countertop, an 8' (2.4 m) ceiling
will allow for a maximum height above the countertop of 29
1
/ 2 " (749) for Model CTWH30 and 27
5
/ 16 " (694) for Model CTWH36.
LOCATION OF
ELECTRICAL
6
7
/8"
(175)
30
1
/2" TO 48
1
/2"
(775 – 1232)
OVERALL HEIGHT
19
1
/8"
(486)
30" (762)
OVERALL WIDTH
4
1
/2"min
(114)
18"
(457)
12"
(305)
21" (533)
OVERALL DEPTH
1
9
/16"
(40)
6"
(152)
OVERALL DIMENSIONS
Cooktop Wall Hoods
Model CTWH30
INSTALLATION SPECIFICATIONS
Cooktop Wall Hoods
19
1
/8"
(486)
4
5
/16"min
(110)
32
11
/16" TO 50
7
/8"
(830 – 1292)
OVERALL HEIGHT
35
7
/16" (900)
OVERALL WIDTH
18"
(457)
12"
(305)
21" (533)
OVERALL DEPTH
9
1
/4"
(235)
1
9
/16"
(40)
8
11
/16"
(221)
SPECIFICATIONS
Model CTWH30
Overall Width 30" (762)
Overall Height 6
7
/8" (175)
(excluding chimney)
Overall Height 30
1
/2" (775)
(including chimney)
Maximum Height 48
1
/2" (1232)
(full extension)
Overall Depth 21" (533)
Bottom of Hood
to Countertop 24" (610) to 30" (762)
Duct Size 8" (203) Round
Discharge Vertical
Internal Blower* 450 CFM
In-Line Blowers* 600 or 1100 CFM
Remote Blowers* 600, 900, 1200 or
1500 CFM
Electrical Supply 110/120 V AC, 60 Hz
15 amp circuit
Shipping Weight 85 lbs (39 kg)
(shell only)
*Blower options vary with the cooking
surface. Refer to the cooktop ventilation
recommendations on pages 115–116.
Model CTWH36
SPECIFICATIONS
Model CTWH36
Overall Width 35
7
/16" (900)
Overall Height 9
1
/4" (235)
(excluding chimney)
Overall Height 32
11
/16" (830)
(including chimney)
Maximum Height 50
7
/8" (1292)
(full extension)
Overall Depth 21" (533)
Bottom of Hood
to Countertop 24" (610) to 30" (762)
Duct Size 8" (203) Round
Discharge Vertical
Internal Blowers* 600 or 900 CFM
In-Line Blowers* 600 or 1100 CFM
Remote Blowers* 600, 900, 1200 or
1500 CFM
Electrical Supply 110/120 V AC, 60 Hz
15 amp circuit
Shipping Weight 100 lbs (45 kg)
(shell only)
*Blower options vary with the cooking
surface. Refer to the cooktop ventilation
recommendations on pages 115–116.
Dimensions in
parentheses are in
millimeters unless
otherwise specified.
