Instructions to Users
USER’S MANUAL
Technical Specifications and Performance Parameters
Item
Specification
Displacement
49.6cc
Overall dimensions(L*W*H)
67” × 26” × 41”
Wheelbase
47”
Minimum ground clearance
4”
Complete vehicle shipping mass
220lbs
Maximum payload
330lbs
Engine model
139QMB
Engine form
Single-cylinder, four-stroke
Engine
Bore × Stoke
39mm×41mm (1.535”x1.653”)
Working volume of cylinder
48 ml
Compression ratio
10.2:1
Model of carburetor
DPD18J
Air filter
Sponge filter
Method of lubrication
Force-feed and splash
Startup way
Kick/Electric start-up
Maximum power/corresponding speed
4.53 HP/8000 RPM
Maximum torque/corresponding speed
2.22 Ft Lbs./5000 RPM
Minimum idling stabilized speed
(1500±100) RPM
Economic fuel consumption
90 MPG
Travelling
system
Model of suspension
Hydraulic spring
Drive mode
Belt drive
Specification/air pressure of tire
Front wheel 3.00-10 32psi. Rear wheel 3.00-10 32psi
