Adjustment of the throttle grip
Check whether the free travel of the throttle is within the correct
range and adjust it if necessary. Please follow the following steps to
adjust the free travel.
1. First, loosen the locking nut.
2. Spinning the regulator will extend or shorten the free travel
of the throttle.
3. When the desired setting is reached, tighten the locking nut,
and slide the protective covering back over the regulator.
Service and Maintenance for the Front Brake
Most models use a front disc brake, which features high heat
dissipation and increased performance.
Adjustment of the front disc brake
1. Place the vehicle on the main stand.
2. Adjust the regulating nut of the front brake to adjust the free
travel of the front braking handgrip to 1/4 –1/2 of an Inch.
1/4 -
The throttle grip should work
smoothly. Any signs of sticking
or binding should be addressed
prior to riding the vehicle.
Adjust the free travel of the front braking handgrip to
between ¼ to ½ an inch.
