Production Data WM8804
w
PD Rev 4.1 September 2007
37
REGISTER
ADDRESS
BIT LABEL CHANNEL
STATUS
BIT
DEFAULT DESCRIPTION
3:0 FREQ[3:0] 27:24 0001 Indicated Sampling Frequency
Refer to S/PDIF specification (IEC 60958-3)
for full details.
R16
RXCHAN4
10h
(read-only)
5:4 CLKACU[1:0] 29:28 11 Clock Accuracy of Received Clock
00 = Level II
01 = Level I
10 = Level III
11 = Interface frame rate not matched to
sampling frequency.
Table 43 S/PDIF Receiver Channel Status Register 4
REGISTER
ADDRESS
BIT LABEL CHANNEL
STATUS
BIT
DEFAULT DESCRIPTION
0 MAXWL 32 1 Maximum Audio Sample Word Length
0 = 20 bits
1 = 24 bits
Note: see table in description of bits 3:1 of
this register,
Audio Sample Word Length
000: Word length not indicated
RXWL[2:0] MAXWL==1 MAXWL==0
001 20 bits 16 bits
010 22 bits 18 bits
100 23 bits 19 bits
101 24 bits 20 bits
110 21 bits 17 bits
3:1 RXWL[2:0] 35:33 000
All other combinations are reserved and
should not be used. See note 1.
R17
RXCHAN5
11h
(read-only)
7:4 ORGSAMP
[3:0]
39:36 0000 Original Sampling Frequency
Refer to S/PDIF specification (IEC 60958-3)
for full details.
Table 44 S/PDIF Receiver Channel Status Register 5
Note 1: MAXWL and RXWL[2:0] bits in recovered channel status data are used to truncate digital audio
interface transmitted data. Truncation replaces the lower data bits with 0. Truncation can be masked
using the WL_MASK control bit. Truncation can be masked by the WL_MASK Refer to received
channel status bit description.
