12
Part
ྙ
ྚ
ྛ
ྜ
ྜྷ
ྞ
12
5
4
6
3
Name
Input BNC
Output BNC
Communication
Port
Base
Safety hook Up
Safety hook
Down
Function
It inputs external image signal
It outpus input image signal to Rapport337
or internally generated Video Test Signals
It is the port of input & output of communication
signal.(Rx+, Rx-,Tx+,Tx-)
It braces Rapport337
It hangs on the neck for safety
It hangs on the neck for safety
