MEASURING RESISTANCE
The unit of resistance is
˟
. The meter sends low current into the circuit so
that resistance can be measured. This current runs all the paths between
probes, and the measured resistance value is all values added among
them.
Part
ྞ
Function
DC
AC
OHM
VOLT
AMP
Description
DC Voltage test
AC Voltage test
Resistance test
(Measuring unit : ˟ )
Voltage test
(Measuring unit : V)
Current test
(Measuring unit : mA, A)
Continuity test
(Starting to beep at below 80 ˟ )
How to measure : Connect the red
lead to and the black lead to ,
as shown in the figure above at left.
and measure the resistance directly
at the resistance measuring mode,
by pressing on the key pad.
