Wood-mizer MP360 - Technical Data and Specifications

TECHNICAL DATA
MP360
Length and width: 2,970 x 1,125 mm (117" x 44")
Height 1,430 mm (56")
Weight 675 kg (1488 lbs)
4-SIDED MOLDING
Width 360 mm (14")
Height 10-130 mm (0.4"-6")
2-SIDED MOLDING
Width 410 mm (16")
Height 10-230 mm (0.4"-9")
PLANING (assembly required)
Width 510 mm (20")
Height 230 mm (9")
TOP HORIZONTAL CUTTER
Diameter 88 mm (3.5")
Width 510 mm (20")
Output 5.5 kW (7.5 Hp)
Rotational speed 6,000 rpm
Cut when planing: 0-8 mm (0-0.3")
Cut when molding Max. 20 mm (0.8")
BOTTOM HORIZONTAL CUTTER
Diameter 72 mm (2.8)
Width 410 mm (16")
Output 4 kW (5.5Hp)
Rotational speed 7,200 rpm
Cut when planing: 0-8 mm (0-0.3")
Cut when molding Max. 10 mm (0.4") (Slot milling: 15 mm (0.6"))
SIDE CUTTERS
Diameter of spindle axel 30 mm (1.2") (with spacers to 1.25")
Cutter height Max. 130 mm (5")
Diameter Max. 140 mm (5.5")
Output 3 kW (Hp)
Rotational speed of side cutters 7,200 rpm
Cutting depth Max. 30 mm (1.2")
SUPPLIED SIDECUTTERS
Type and quantity 2 x TB90
Diameter, body 90 mm (3.5")
Height, body 40 mm (1.6")
Cut, type and width Planing knife HSS, 50 mm (2")
FEED, PLANED VARIATOR
Output 0.75 kW (1 Hp)
Feed rate 3-15 m/min (10-49 ft/min)
ELECTRIC SYSTEM
Total output 16.25 kW (22 hp) All motors are equipped with overheating protection.
Electrical connection 3-phase, 400 V, 32 A, 20A fuses are sufficient for less demanding production.
