Loc. Description Qty Loc. Description Qty
138 Bearing Housing,
Rollers, Complete
8 185 Motor, Feed, USA 1
139 Bronze Bushing, Feed
Rollers
14 187 Cover, Worm Gear 1
143 Feed Roller, Grooved 4 189 Crank, Height Setting 1
144A Polyurethane Feed
Rollers
1 193 Chain Tensioning Arm 3
144B Shear Pin, Rubber
Roller
1 194 Chain Tensioning Wheel 3
148 Motor, Top Cutter, 5.5
KW / 7,5hp
1 196 Stop Plate on Infeed
side
1
149 Belt Pulley, Motor,
Top Cutter
1 197 Mount, Plastic, Cover,
Back
1
152 Poly-V Belt, Top
Cutter
1 198 Plastic Cover, Back,
Complete
1
153 Chain, Height
Adjustment
1 201 Chain Guard Plate 1
154 Trapezoidal Thread
Bar for Crank table
1 211 Height Setting Handle,
Feed table
1
155 Chain Sprocket 4 212 In-Feed Table 1
156 Bearing
Washer,Top/Bottom
8 216 Adjusting Handle, fence 1
157 Bronze Bushing,
Bearing Washer,
Top/Bottom
8 220 Fence 1
163 Trapezoidal Thread
Bar, Table
3 223 Locking
Handle,Adjustable,
M10x20
6
165 Reinforcement Plate,
Top Cutter
1 224 Locking
Handle,Adjustable,
M8x25
6
174 Cover Plate, Slide 1 225 Locking
Handle,Adjustable,
M10x40
2
179 Circuit Breaker 1 232 Electrical Distribution
Box, USA, Comp
1
180 Oversize Preventer 1 253 Out-Feed Table 1
181 Infinitely Variable
Feed, Complete
1 259 Trapezoidal Thread Bar
Extender, Slide
1
182 Worm Gear 1 260 Crank, Side Cutter,
Complete
1
184 Planetary Gear 1 267 Locking Knob, Door 1
184B Adjustment Knob,
Feed
1 268 Cover Plate, Chip Duct 1
185 Motor, Feed 400/230V 1 269 Handle, Cover 1
272 Chip Duct, Top Cutter 1
