Woods MDX14 - Product Description; Control Panel Functions; Installation Clearances; Drainage Options

GB
11
Operating Instructions
F
1. Front shell
2. Right shell
3. Water tank
3. Product description
A
1. Front shell
2. Casters
3. Top panel
B
1. Filter
2. Continuous drain port
C
1. Water tank
D
1. Top panel
E
Control panel
1. POWER button: Start or stop the unit
2. TIMER button: Set the timer, query timer
and cancel timer.
3. SPEED button: Fan will run at low speed or
high speed.
4. UP button: Adjust the humidity or timing.
5. DOWN button: Adjust the humidity or
timing.
6. MODE button: Fan --- Eco --- Dryer --- Auto
--- Dehumidication
G
1. Control panel
2. Filter
3. Continuous drain port
4. Rear shell
5. Air outlet
6. Left shell
7. Caster
H
1. Keep the top panel from other objects at
least 50cm.
2. Keep a distance of above 30cm between
the machine and the surrounding objects
or walls.
I
1. Manual drainage
2. Continuous drainage
PRODUCT DESCRIPTION
