Woods PRD6000E - English; Table of Contents; Specifications; General Information

Introduction 3
MAN1260 (4/09/2018)
TABLE OF CONTENTS
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY DECALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
OWNER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
DEALER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
DEALER CHECKLIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
PARTS LISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
BOLT TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
BOLT SIZE CHART & ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
PRODUCT WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
REPLACEMENT PARTS WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
SPECIFICATIONS
GENERAL INFORMATION
 Some illustrations in this manual show the equipment with safety
shields removed to provide a better view. This equipment should never
be operated with any necessary safety shielding removed.
The purpose of this manual is to assist you in operating and maintaining your
mower. Read it carefully. It furnishes information and instructions that will help
you achieve years of dependable performance. These instructions have been
compiled from extensive field experience and engineering data. Some informa-
tion may be general in nature, due to unknown and varying operating condi-
tions. However, through experience and these instructions, you should be able
to develop procedures suitable to your particular situation.
The illustrations and data used in this manual were current at the time of print-
ing. However, due to possible inline production changes, your machine may
vary slightly in detail. We reserve the right to redesign and change the
machines as may be necessary without notification.
Throughout this manual, references are made to right and left directions. These
are determined by standing behind the tractor facing the direction of forward
travel.
PRD6000E
PRD7200E PRD8400E
3-Point Hitch Category 1 Category 1 Category 1
Cutting Width 1524 mm (1.5 m) (60") 1829 mm (1.8 m) (72") 2134 mm (2.1 m) (84")
Cutting Height Range 25.4 - 139.7 mm
(1" - 5-1/2")
25.4 - 139.7 mm
(1" - 5-1/2")
25.4 - 108.0 mm
(1" - 4-1/4")
Operating Weight with
Chain Shielding
296 kg (653 lbs) 326 kg (719 lbs) 376 kg (830 lbs)
Blade Speed (feet per minute) 5517 m/min (18,100) 5486 m/min (18,000) 5456 m/min (17,900)
Blade Speed (RPM) 3,295 2,748 2,329
Blade Spindles 3 3 3
Number of Blades 3 3 3
Universal Drive Series ASAE Cat. 3 ASAE Cat. 3 ASAE Cat. 3
Caster Wheels 101.6 x 254 mm
(4.00 x 10")
101.6 x 254 mm
(4.00 x 10")
101.6 x 254 mm
(4.00 x 10")
Tractor PTO Speed RPM 540 540 540
Recommended Maximum
Tractor Horsepower
60 60 60
Mower Frame Thickness 4.2 mm (8 ga) 4.2 mm (8 ga) 4.2 mm (8 ga)
