How to troubleshoot a Woodward 8406-121 that does not power up?
If your Woodward Control Unit does not power up, first check the input power supply on terminals 1 and 2, ensuring it's between 9 to 32 Vdc. Also, verify that the polarity of the power supply to the unit is correct, as reversed polarity can prevent it from powering on.
Why voltages displayed by Woodward 8406-121 are different than measured?
If the voltages or currents displayed by your Woodward Control Unit are different from the measured parameter, it might be due to inaccurate calibration of the PT inputs. Calibrate the appropriate PT input channel(s) to resolve this issue.
What to do if Woodward 8406-121 cycles on and off when cranking?
If your Woodward Control Unit powers up but then cycles on and off when cranking, this could be due to a weak engine battery, or the engine battery voltage dropping below 6 Vdc during cranking. Try charging or replacing the engine battery.
Why generator voltages are very small on Woodward 8406-121?
If the displayed generator voltages are very small on your Woodward Control Unit, the issue might stem from faulty wiring of the generator Potential Transformers (PTs). In this case, verify the wiring of generator Potential Transformers (PTs). Another potential cause is that the generator PT inputs are improperly calibrated.
What to do if I/O STATUS shows relay is energized but alarm does not occur on Woodward 8406-121 Control Unit?
If the I/O STATUS screen on your Woodward Control Unit shows a relay is energized, but the corresponding action (like an alarm) does not occur, the problem is likely due to faulty wiring of the relay output contacts. Verify the wiring of the relay output contacts to ensure they are correctly connected.
How to fix discrete inputs not showing active on Woodward 8406-121?
If discrete inputs don’t show active in the I/O STATUS screen when switches are activated on your Woodward Control Unit, it could be caused by faulty wiring of the discrete input switches. Verify the wiring of these switches.
Why generator voltage fluctuates on Woodward Control Unit?
If the generator voltage fluctuates or is unstable at no load on the generator with your Woodward Control Unit, the AVR dynamics might be improperly set up. You should tune the AVR dynamics for stable operation.
General| Brand | Woodward |
|---|---|
| Model | 8406-121 |
| Category | Control Unit |
| Language | English |
Explains terminal block usage, wire types, and grounding.
Details PT input wiring, ratios, and configuration for voltage sensing.
Describes CT wiring and input ratings for current sensing.
Outlines the structure and access to system configuration menus.
Describes different load control strategies like Droop, Baseload, and Process.
Guides users through calibrating analog inputs and outputs for accuracy.
Steps for calibrating voltage and current transformer inputs.
Essential checks and configuration steps before starting the generator.
Step-by-step procedure for initial startup and parameter checks.
Guidelines for safely applying load to the generator set.
Diagnosing issues with inputs, outputs, power, and relay contacts.
Troubleshooting engine start, speed, and sensor input issues.
Diagnosing problems with phase matching, voltage, and breaker closure.
Addressing problems with load sharing, ramping, and unit sequencing.
Resolving issues with mains detection and RS-485/RS-422 network communication.
