45
Mounting the front wheel (not necessary for woom online shop customers)
Remove the plastic spacer from
the brake caliper.
Unscrew the through axle from
the front fork. The quick-re-
lease lever must be located in
the recess.
Remove the plastic protective
disc from the brake disc (do not
pull the spacer sleeve with it!).
Insert the front wheel into the
fork. The brake disc must be
on the left! Make sure that the
brake disc is correctly seated in
the brake caliper between the
brake pads.
Push in the through axle and
tighten. The quick-release lever
must be located in the recess.
Then close the quick-release
lever.
CAUTION
When mounting the front wheel into the fork, make sure that the spacer sleeves in the
hub are mounted on both sides. When removing the plastic disc, make sure that the
black spacer sleeve remains on the hub! It may remain stuck on the plastic protective
disc. If this is the case, remove it from the plastic disc and put it back onto the hub.
