46
Mounting the saddle
Measuring the saddle height – see minimum saddle height in Section 11.2 on page 61
Open seatpost clamp with hex
key.
Position the seat post at the
appropriate height (see hints
on page 15 for adjusting seat
height).
Tighten the seatpost clamp
with a hex key.
ATTENTION
Observe minimum insertion depth! See min. mark on seat post.
Do not overtighten the internal hex screws.
Do not set the saddle lower than the minimum saddle height!
4 mm 4 mm
