Woom UP - 6.5 Electric Drive and Charging

47
Installing the pedals
In-
stalling the reectors
Screw the pedal marked "R" in the direction of
the arrow into the right crank arm and tighten
with a hex key.
Screw the pedal marked "L" in the direction of
the arrow into the left crank arm and tighten
with a hex key.
Attach the clip-on reectors to
the spokes.
Mount the white reector to the handlebar and the red reector
to the seat post.

HINTS
Correct seat height: With your child sitting on the saddle,
have them place their heel on the pedal (the one in the lowest
position) and stretch out their leg. Sitting on the saddle and
with the saddle height adjusted, your child should be able
to touch the ground with both feet and remain in a stable
position. Set the saddle lower for beginners.
8 mm 8 mm
