Worcester danesmoor 26/32

13
Fig. 10. Oil Supply.
Fig. 11. Oil Pipe Installation.
(b) Single Pipe System.
RS Appliance
(a) CF Bracket.
CF Appliance
(c) Double Pipe System.
(a) Single pipe system
Oil tank
Oil tank
Sludge cock
Maximum oil level
H = 4 m (13 ft) maximum
H = 3.5 m (11.5 ft) maximum
Tank raised 1 in 24
(40 mm per metre)
Fire valve to
BS 799 Part 2
Fire valve to
BS 799 Part 2
Isolating
valve
Isolating
valve
Paper
element
oil filter
Fire detection
element
Filter
Filter
Burner
Burner
Wall
Wall
(b) Double pipe system.
H = 0.3 m (1 ft) minimum
Sludge cock
Burner
oil pump
Flexible
oil hose
Open
grommet
Turn fully clockwise
to isolate
Blind
grommet
Air
bleed
Paper
element
oil filter
Tank raised 1 in 24
(40 mm per metre)
Isolating
valve
Non return
valve
Non return
valve
Fire detection
element
Isolating
valve
Burner
oil pump
10mm or 12mm
copper pipe
1/4" BSP female x
10/12mm
compression coupling
(not supplied)
10mm
copper pipe
10mm
copper pipe
Retaining
clip
Isolating
valve
Isolating
valve
Pipe support
bracket
Turn fully
clockwise
to isolate
