Worcester danesmoor 26/32

24
(b) 15/19
(c) 20/25 and 26/32
(d) 32/50 and 50/70
ENSURE THAT ALL BAFFLES ARE SEATED IN POSITION
(a) 12/14
Baffle
retainer
Baffle
Baffle
Heat
shield
Fig. 25. Location of Boiler Flueway Baffles.
Baffle
retainer
Cap
retainer
Access door
Cap Retainer
Cap
Transit
retainer
(remove & discard)
Cap
Baffle
Heatshield
Burner
Mounting
Flange
Fig. 26. Location of Cap retainer
(32/50 and 50/70 models)
