Worcester danesmoor 26/32

7
Fig. 2. Conventional Flue Appliance (CF/LLD).
Top panel
Electrical top coverFire valve clip
Electrical panel
Isolating valve
Front panelSide panel
Burner
Optional
programmer
Thermostat
knob
Optional
pump
location
Burner seal
gasket
Burner locking
screw
Side panel
locking screw
(
A)
Control Box Assembly
Manual reset over-
heat thermostat
phial
Automatic reset high
limit thermostat phial
Control thermostat
phial
Phial retaining
plug
Split pin
