4
TECHNICAL INFORMATION
The Danesmoor range of oil-fired boilers can provide both
domestic hot water and full central heating, with outputs ranging
from 12kW to 70kW (40,000 to 239,000 Btu/h). Domestic hot
water must be supplied via a conventional indirect hot-water sys-
tem, utilising an indirect double-feed cylinder.
The appliance is supplied without a circulating pump, but
there is provision to locate a pump within the boiler casing. For
further details please consult your installer.
The temperature control knob, overheat reset button and
lockout reset button are all located behind the cabinet front panel.
To remove the front panel pull forwards at the bottom end to
release the lower two ball studs and repeat the procedure at the
top end to release the upper ones. Take care not to pull the bottom
end too far forwards as this may damage the spring clips.
TO START YOUR BOILER (See Fig. 1).
(a) Switch on the electrical mains supply to the boiler.
(b) Ensure that any external controls connected to the boiler, such
as a room thermostat, are on a high setting.
(c) If a programmer is fitted, set it to the correct time of day and
position the selectors to ON.
(d) Turn the thermostat control knob to the desired position (see
section Temperature Control).
ACCESSING YOUR BOILER
CONTROLS
HOW TO START YOUR
BOILER
