USER INSTRUCTIONS & CUSTOMER CARE GUIDE
8-716-106-255a (03.05)
CONTROLS
1
CONTROLS
A Central heating temperature control
B Lock-out indicator
C Heating demand indicator
D Optional internal programmer (see instructions
supplied with programmer for details)
E Reset button - burner lock-out (behind front
panel)
F Reset button - boiler overheat thermostat (behind
front panel)
G Reset button - flue overheat thermostat (behind
front panel)
H Holder for User Guide
J Front panel
OFF
TIMED
ONCE
ON
OFF
TIMED
ONCE
ON
HOT WATER CENTRAL HEATING
ADVANCE SET ? ADVANCE
SELECT SELECTYES
DC
EF
A
B
H
JG
