Parts description
1 Quick-action safety chuck
2 Torque adjustment ring
3 Mode selection ring (screwing/drilling/hammer drilling)
4 Gear switch
5 Charge level display
6 Right-handed/left-handed rotation selector
7 Thread for belt-clip
8 Rechargeable battery
9 Rechargeable battery release button
10 Battery receptacle
11 On/Off switch (with speed control)
12 LED work light
13 Additional rechargeable battery
14 Magnetic bitholder
15 Bits
16 Drill bits (HSS spiral drill bits)
17 Belt-clip (with screw)
18 Charger
19 Storage case (not illustrated)
This user manual can also be downloaded as a PDF from our website
www.meister-werkzeuge.de.
