Fig. H
Before assembly, always switch off the machine and remove the mains plug
from the wall outlet.
Part no Description Position
102038 Saw blade screw M6x16 39
102039 Flange 40
102040 Spindle lock 52 - 54 + 56 + 57
102041 Carbon brush set 72
102042 Switch 74
102043 Dustbag -
