3Assembly and parts list
Fig. A
1. On/off switch
2. Lock off button
3. Spindle lock
4. Angle stop
5. Scale for the fence angle
6. Cutting depth adjustment knob
7. Knob for angle adjustment
8. Knob for height adjustment
9. Scale for the height adjustment
10. Base plate
11. Dust bag connection
11
3
5
7
4
1
2
6
8
10
9
BJM6003 Ma EN-IRL 1202-22.indd 8 2/22/12 4:26 PM

Workzone WBJ-900 Specifications

General

Brand	Workzone
Model	WBJ-900
Category	Power Tool
Language	English
