4Instructions
Never use the spindle lock while the machine is working.
Switching on and off
Fig. A
• This machine is equipped with a safety switch. To switch the machine on, first press the
lock off button (2) and then press the on/off switch (1).
• To switch the machine off, depress the on/off switch, the switch will automatically move
to the ‘off’ position.
Never use the spindle lock to stop the motor.
Marking the workpieces
Fig. C
Before starting with the Biscuit Jointer the workpieces must be marked as following.
• Place the two workpieces, which must be connected, on top of each other.
• Fasten the workpieces and mark the center of the groove.
• The space between two grooves should be 10-15 cm, this doesn’t concerns for smaller
workpieces. Smaller workpieces don’t have to be marked.
Positioning of the machine
Based on the size of the workpieces the machine can be positioned in several ways.
Large workpieces
Fig. D
• Place the machine near the workpiece.
• The middle of the base plate (this point is marked on the base plate) must facing the
centre of the groove in the workpiece (see marking the workpiece).
Small workpieces
Fig. E
• Place the machine near the workpiece.
• The side of the machine must be facing the side of the workpiece.
Workpieces thinner than 16 mm
Fig. F
• Place the machine near the workpiece.
BJM6003 Ma EN-IRL 1202-22.indd 15 2/22/12 4:26 PM
