First remove the screw on the
battery cover and remove the
battery cover itself. Then
install 4 AA batteries. Make
sure they are installed with the
correct polarity. Replace the
battery cover and screw.
CAUTION:
1. Make sure the polarity of the
batteries are correctly installed.
2. Do not mix old and new
batteries.
3. Do not mix different types
of batteries.
INSTALLING THE TRANSMITTER BATTERIES
INSTALLING THE DRONE BATTERY
Battery Type Battery Specification Usage Duration
Charge Time
BATTERY PACK SPECIFICATIONS
CAUTION WHILE CHARGING:
Do not charge with batteries still installed. Do not charge battery unsupervised. Do not immediately charge after
use. Do not overcharge battery. Ideal charge time is 60-70 minutes. Overcharging can cause a catastrophic
failure. Always charge on dry and ventilated areas away from any heat source or flammable materials. Always
use the original USB charging cable provided. Promptly change and replace old or defective batteries.
Li-Ion Battery 3.7V 600mAh
Flight Duration 6 minutes Charging Time 60-70 minutes
CHARGING THE DRONE BATTERY
Switch off the power and open the
battery compartment. Disconnect
the battery cable from the drone and
remove the battery from the drone
before charging.
WIFI F/C
ON OFF
WIFI F/C
ON OFF
Plug the included USB charging cable to a computer. The LED light on
the USB charger will turn on. Connect the battery pack and the LED light
will turn off. The LED light will turn back on when the battery is fully
charged. A full charge will take approximately 60-70 minutes.
DO NOT CHARGE THE BATTERY OVERNIGHT
DO NOT CHARGE THE BATTERY WITHOUT SUPERVISION
Open the battery compartment as
shown. Connect the red plug on the
battery to the power port inside. Insert
battery into compartment and close
the cover.
Locate the On/Off Switch on the
underside of the drone. Switch to the
ON position to power on the drone.
Battery Cover
4 AA Batteries
To Next Page
