Wortmann Terra Series User Manual

48
49
EN
Display connection options
The HDMI port (High Definition Multimedia Interface)
• Digital multimedia port
• Also standard in TV environment
• Sound is also transmitted in addition to video
• Typical resolution: full HD= 1920x1080p/60Hz
• Enables direct, uncomplicated connection
of the PC to modern TFTs+LCD-TVs
The VGA port/D-Sub
• A nalog port
• Not recommended for high resolution
TERRA MINI PC
TERRA MICRO PC
Back panel connectors
USB 3.0 LAN mini
display
Port
HDMI power
kensington-
lock
head-
phone
USB 3.1
typ A
USB 3.1
typ C
DC IN display
port
HDMI RJ45/1 Gbit USB 2.0
connector for
ext. power button
WLAN
RS 232RS 232/422/485

Wortmann Terra Series Specifications

General

Category	Desktop
Series	Terra
Processor	Intel Core i5 or i7
Graphics	Integrated Intel UHD Graphics or dedicated NVIDIA GeForce/AMD Radeon (depending on the specific model)
Operating System	Windows 10 or Windows 11
Ports	USB 3.0, HDMI, Ethernet, audio jack
