12
EN
D. Open the rear of Landroid and insert the PowerShare battery into the slot until it clicks (fig.12)
E .Place Landroid on charge by making sure a deep contact is established with the base (fig. 13). The LED will blink green; once the
battery is fully charged, the LED will turn solid green.
IN
10
11
CLICK!
12
Landroid box includes two small, waterproof boundary wire connectors. They can be used for the following:
A. When your lawn has a very long perimeter and you need extra boundary wire to complete the installation. Please do not exceed
300m of boundary wire: this is the maximum length of the boundary wire perimeter
B. When the boundary wire is cut by accident and you need to fix it
C. When you decide to rework your garden in the future and need to modify the original boundary wire installation
The connectors are waterproof and provide optimal electric connection.
D. Insert both ends of the wire into any two of the three holes of the connector; no need to strip the wires
E. Insert the wires fully until both wire ends are visible on the other side of the connector
F. Press the connector firmly by using a pair of pliers
Attention: it is not recommended to simply splice the boundary wire with insulating tape or use a screw terminal block for connection.
A broken circuit may occur after a period of time as soil moisture can oxidize the wire.
2.3.9 Joining up the boundary wire
F.Let Landroid charge the battery for a while. Whilst it is charging you may want to take a well-deserved break: get familiar with the
following instructions, and connect Landroid to your Wi-Fi network.
13
