9
3 in 1: Trimmer / Edger / Mini mower
EN
1. REAR HANDLE
2. BATTERY PACK
3. TELESCOPIC SHAFT
4. PIVOT HEAD LOCKING KNOB
5. SAFETY GUARD
6. FLOWER GUARD/EDGE GUIDE
7. AUXILIARY HANDLE
8.
TELESCOPIC SHAFT ADJUSTMENT TRIGGER
9. LOCK OFF BUTTON
10. ON/OFF SWITCH
11. AUXILIARY HANDLE LOCKING LEVER
12. EDGE /TRIMMING SUPPORT WHEELS
13. LINE CUTTER
14. LOWER SHAFT COUPLING
15. UPPER SHAFT
16. MOTOR HOUSING OF TRIMMER HEAD (See Fig. H)
17. LINE FEED BUTTON (See Fig. P)
18. SPOOL CAP COVER (See Fig. Q2)
19. CAP RELEASE LATCH (See Fig. Q2)
20. SPOOL (See Fig. Q2)
21. CUTTING HEAD (See Fig. Q2)
22. EYELET (See Fig. Q2)
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WG169E WG169E.1 WG169E.2 WG169E.5 WG169E.9 (1-designation of machinery,
representative of Grass Trimmer)
WG169E WG169E.1 WG169E.2 WG169E.5 WG169E.9
Voltage 20V
Max*
No load speed 7600/min
Cutting diameter 30cm
Line diameter 1.65mm
Charging time 5hr 1hr /
Machine weight 2.6kg 2.2kg
*Voltage measured without workload. Initial battery voltage reaches Maximum of 20volts. Nominal voltage is
18volts.
