14
Cordless Grass Trimmer
EN
SUGGESTED BATTERIES
AND CHARGERS
Category Type Capacity
20V Battery WA3014 4.0 Ah
20V Charger WA3880 2.0 A
We recommend that you purchase your accessories
from the same store that sold you the tool. Choose
the type according to the work you intend to
undertake. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
NOISE DATA
A weighted sound pressure
L
pA
= 75.2 dB(A)
K
pA
3.0 dB (A)
A weighted sound power L
wA
= 89.6 dB(A)
K
wA
3.0 dB (A)
Wear ear protection
VIBRATION INFORMATION
Typical weighted vibration a
h
Uncertainty
WARNING:The vibration emission value
during actual use of the power tool can differ
from the declared value depending on the ways in
which the tool is used dependant on the following
examples and other variations on how the tool is
used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well
maintained
Using the correct accessory for the tool and
ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any
anti vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.
This tool may cause hand-arm vibration syndrome
WARNING:To be accurate, an estimation of
exposure level in the actual conditions of
use should also take account of all parts of the
operating cycle such as the times when the tool
is switched off and when it is running idle but not
the exposure level over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instruc-
tions and keep well lubricated (where appropriate)
If the tool is to be used regularly then invest in anti
vibration accessories.
Avoid using tools in temperatures of 10
o
C or less
Plan your work schedule to spread any high vibra-
tion tool use across a number of days.
4. INTENDED USE
The trimmer is widly used for cutting grass and sim-
ilar soft vegetation and for trimming grass edges.
5.ASSEMBLY & OPERATION
Action Figure
ASSEMBLY
Assembling the Safety Guard
See Fig. A1,
A2
Support Wheels
NOTE: There are three optional
Support Wheels to attach when
assisting in Trimming and Edging.
Fig. B1 is for Edging. Fig. B2 and B3
is for Trimming.
See Fig. B1,
B2, B3
Installing and Removing the Battery
Pack
Your Battery Pack is UNCHARGED
and it must be fully charged once
before it is used.
See Fig. C
Checking the Battery Condition See Fig. D1
Charging the Battery Pack
More details can be found in char-
ger’s manual
WARNING! The charger and
battery pack are specially
designed to work together so do not
attempt to use any other devices.
into your charger or battery pack
connections because of an electrical
failure and hazard will occur.
See Fig. D2
OPERATION
