WG349E WG349E.9
WA0307
20V Cordless Pole
Saw
COMPONENT LIST
1. CHAIN
2. CHAIN TENSIONING KNOB
3. CHAIN COVER
4. SAW HEAD ADJUSTMENT KNOB
5. SAW HEAD LOCKING-BUTTONS
6. OIL FILLER CAP
7. GUIDE BAR
8. OIL LEVEL WINDOW
9. DRIVE SPROCKET
10. CHAIN DIRECTION SYMBOL
11. BAR LOCATING TABS
12. FASTENING BAR BOLT
13. BAR PAD
14. BUMPER SPIKE
15. OIL OUTLET
16. BAR AND CHAIN SHEATH
17. POLE SAW ASSEMBLY LEVER
18. INNER POLE CLAMPING LEVER
19. ON/OFF TRIGGER
20. BATTERY PACK*
21. BATTERY PACK RELEASE BUTTON*
22. REAR HANDLE
23. EXTENSION POLE LOCK-OFF BUTTON
24. EXTENSION POLE ROTATION BUTTON
25. SHOULDER STRAP HOOKS
26. SHOULDER STRAP
27. BAR TENSIONING PLATE (SEE FIG. A)
* Not all the accessories illustrated or described are included in standard delivery.
