3. GRASS COLLECTION BAG FITTING (See Fig.
C1, C2, C3)
1) Switch off the mower and Unplug from the
mains—Wait for the blade to come to a complete
S T O P.
2) Pick up the Grass Collection Bag by the handle,
and position the Grass Collection Bag on the lower
hooks (a) on the mower deck (See Fig. C2).
3) Release the safety guard to lock the grass bag
into position. Ensure the Grass Collection Bag is
installed securely (See Fig. C3).
NOTE: Depress the Grass Collection Bag slightly to
ensure that it is completely installed.
4. REMOVING/EMPTYING
Hold the Grass Collection Bag, lift the Safety Flap (9)
and hold up. Remove the Grass Collection Bag.
WARNING! Always check the safety flap can
close the discharge outlet tightly before using.
Never lift the Safety Flap when the lawn mower is
being used without fitted grass bag.
a
9
1
2
C1
C2
C3
