Worx WX092 Manual

9
20V Multi-Function Inflator EN
the accessible emission and/
or personal protective means
(such as eyewear, clothing)
which would limit the potential
exposure to the emitted energy.
Optical hazard value exceeds applicable EL V
by factor of A: reduce exposure duration by
factor of A or attenuate emission by factor of A
Distance X
1
: EHV = 1
Optical hazard value = ELV
Distance X
2
: EHV = A
100
10
A
1
EHV
X
2
X
1
0.1
Distance
Figure 1 – Example of
graphic presentation of
distant dependent emission
hazard values
SYMBOL
To reduce the risk of injury, user must
read instruction manual
Warning
Wear eye protection
Hearing protection must be worn
Risk of high temperature
Waste electrical products must not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or
retailer for recycling advice.
COMPONENT LIST
1. INCREASE AIR PRESSURE BUTTON
2. STARTSTOP BUTTON
3. DECREASE AIR PRESSURE BUTTON
4. POWER BUTTON
5. WORKLIGHT
6. ADAPTER HOLDER
7. HOSE
8. BATTERY PACK
9. HOSE CLAMP
10. AIR CHUCK
11. AIR CHUCK CLAMP
12. PRESTA VALVE ADAPTER SEE FIGURE E2
13. SPORT BALL NEEDLESEE FIGURE E3
14. TAPERED ADAPTER SEE FIGURE E4
15. WORKLIGHT BUTTON SEE FIGURE F
*Not all the accessories illustrated or described are
included in standard delivery
TECHNICAL DATA
WX092 WX092.X***
Rated voltage 20 V Max**
Inflation efficiency
(0 to 2.4 bar for
215/55R17 tires)
4 mins
Working pressure
10 bar(150 psi) Max
8 bar (120 psi) 2.5 mins/7.5 mins
Weight (Bare tool) 0.95 kg
** Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal voltage is
18 volts.
