Worx WX423 Safety And Operating Manual

7
Electric Circular Saw WX423
1. LOCK OFF BUTTON
2. SOFT GRIP HANDLE
3. HEX KEY
4. ON/OFF SWITCH
5. SPINDLE LOCK BUTTON
6. LOWER BLADE GUARD
7. LOWER GUARD LEVER
8. FIXED UPPER GUARD
9. DUST EXTRACTION OUTLET
10. VACUUM ADAPTER
11. DEPTH ADJUSTMENT LEVER
12. BASE PLATE
13. SAW BLADE (See Fig. A)
14. BLADE BOLT (See Fig. A)
15. PARALLEL GUIDE
16. PARALLEL GUIDE CLAMPING FIXTURE
17. OUTER FLANGE (See Fig. A)
Not all the accessories illustrated or described are included in standard delivery.

Worx WX423 Specifications

General

Blade bore	15 mm
Blade diameter	85 mm
Bevel adjustment	-
Idle speed (max)	3600 RPM
Cutting depth (90º)	27 mm
Input power	400 W
Power source	AC
Spindle lock	Yes
Product color	Black, Orange
Suitable for materials	Metal, Plasterboard, Plastic, Tile, Wood

Weight and Dimensions

Depth	90 mm
Width	320 mm
Height	160 mm
Weight	1400 g
