Worx WX423 Safety And Operating Manual

8
Electric Circular Saw WX423
TECHNICAL DATA
Type WX423 (4-designation of machinery, representative of Saw)
Voltage
230-240V~50Hz
Rated power 400W
No load (rated) speed 3600/min
Blade size
TCT blade 85mm x 15mm x 1.2mm x 24T
HSS blade 85mm x 15mm x 1.2mm x 44T
Diamond disc 85mm x 15mm x 1.2mm x 60G
Max cutting depth 27mm
Recommended maximum material thickness
Wood 27mm
Aluminum 3mm
PVC pipe (radius) 13mm
Tile 8mm
Sheet steel 0.91mm
Protection class
/ll
Bare tool weight
1.4kg
ACCESSORIES
TCT Blade: 24T for wood 1
Parallel Guide 1
Vacuum Adaptor 1
Hex Key 1
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.

Worx WX423 Specifications

General

Blade bore	15 mm
Blade diameter	85 mm
Bevel adjustment	-
Idle speed (max)	3600 RPM
Cutting depth (90º)	27 mm
Input power	400 W
Power source	AC
Spindle lock	Yes
Product color	Black, Orange
Suitable for materials	Metal, Plasterboard, Plastic, Tile, Wood

Weight and Dimensions

Depth	90 mm
Width	320 mm
Height	160 mm
Weight	1400 g
