Electric Circular Saw WX426
1. SOFT GRIP HANDLE
2. FIXED UPPER GUARD
3. VACUUM ADAPTER
4. DUST EXTRACTION OUTLET
5. PARALLEL GUIDE CLAMPING FIXTURE
6. PARALLEL GUIDE
7. LOWER BLADE GUARD
8. BASE PLATE
9. LOWER GUARD LEVER
10. DEPTH ADJUSTMENT LEVER
11. LOCK OFF BUTTON
12. ON/OFF SWITCH
13. HEX KEY
14. SPINDLE LOCK BUTTON
15. LASER
16. SAW BLADE (See Fig. A)
17. BLADE BOLT (See Fig. A)
18. OUTER FLANGE (See Fig. A)
19. LASER ON-OFF SWITCH (See Fig. E)
20. LASER BATTERIES (TWO) (See Fig. F2)
Not all the accessories illustrated or described are included in standard delivery.

Worx WX426 Specifications

General

Input power	400 W
Power source	AC
Dust blower	Yes
Product color	Aluminium, Black, Orange
Built-in light	-
Suitable for materials	Metal, Particle board, Plasterboard, Plastic, Tile, Wood
Blade bore	15 mm
Blade diameter	85 mm
Idle speed (max)	3000 RPM
Cutting depth (90º)	- mm

Weight and Dimensions

Depth	3200 mm
Width	90 mm
Height	180 mm
Weight	1800 g
