Compact Circular Saw EN
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
ASSEMBLY AND OPERATION
Action Figure
Mounting and Removing the Blade
NOTE: Lock or loose the blade
bolt, the spindle lock button
should be pressed.
WARNING: Always
remove the battery before
changing the blade!
See Fig. A
Safety switch and On/Off trigger
WARNING: To avoid
cutting injury from the
sharp blade, please don’t put
your hands around the Base
Plate.
NOTE: Keep the dust adapter
connected to dust collecting
device when using the tool.
See Fig. B
Rip and Cross Cutting
NOTE: The cutting line of saw
blade is aligned with the cutting
mark 0°.
See Fig. C1, C2
Parallel Guide See Fig. D1, D2
Adjusting the Cutting Depth See Fig. E1, E2
Adjusting the Cutting Angle
NOTE: The cutting line of saw
blade is aligned with the cutting
mark 45°.
See Fig. F
Pocket /Plunge See Fig. G1, G2
Sawdust Removal See Fig. H
WORKING HINTS FOR YOUR
TOOL
Your power tool shall not be used for cutting plastics.
The blade may become very hot after prolonged
usage, please do not touch it.
MAINTAIN TOOLS WITH
CARE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Keep tools sharp and clean for better and safer
performance. Follow instructions for lubricating and
changing accessories. Inspect tool cords periodically
and if damaged, have repaired by authorized service
facility. Your power tool requires no additional
lubrication or maintenance. There are no user
serviceable parts in your power tool. Never use
water or chemical cleaners to clean your power tool.
Wipe clean with a dry cloth. Always store your power
tool in a dry place. Keep the motor ventilation slots
clean. Keep all working controls free of dust. If the
supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Periodically clear dust and chips from guard and
base to ensure proper performance.
