Jigsaw EN
10
TECHNICAL DATA
Type WX477 WX477.1 WX478 WX478.1 WX479 (460-479-designation of machinery, representative
of Jig Saw)
WX477 WX477.1 WX478 WX478.1 WX479
Rated Voltage 220-240V~50Hz
Rated power 550W 650W 750W
Rated No-load speed 3100/min 1000-3100/min
Stroke length 20mm
Bevel capacity ±45°
Protection Class
/II
Cutting depth
Wood 65mm 90mm 100mm
Aluminum 12mm 20mm
Steel 6mm 8mm 10mm
Weight 2.2kg 2.3kg
1. VARIABLE SPEED CONTROL ONLY FOR WX478 WX478.1 WX479
2. ONOFF SWITCH
3. LOCKON BUTTON
4. SOFT GRIP HANDLE
5. ALLEN KEY
6. ANGLE PLATE
7. BASE PLATE
8. ROLLER GUIDE
9. PARALLEL GUIDE FIXING
10. FINGER PROTECTION GUIDE
11. PENDULUM FUNCTION CONTROL
12. PARALLEL GUIDE ONLY FOR WX478 WX478.1 WX479
*Not all the accessories illustrated or described are included in standard delivery.
