Jigsaw EN
13
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your local authorities or retailer for recycling advice.
TROUBLESHOOTING
Symptom Possible Causes Possible Solution
Tool will not start when
power on
• Power cord is not plugged.
• Check to make sure power cord is
connected well into a working outlet.
Poor cut quality
• Blade is worn out.
• Blade is assembled incorrectly
• Pushing rate is too fast.
• Make sure the blade is sharp and not
broken.
•
Make sure the blade is installed properly.
Push the machine slowly.
Work efficiency is low.
• Blade is worn out
• Incorrect speed setting
• Incorrect Pendulum function
setting
• Change to a new blade.
• Adjust the variable speed control
according to the material
• Adjust the pendulum function control
according to the material
Blade is not clamped tightly by
the Blade Holder.
• Blade is not inserted into place
fully.
Dismantle the blade and reinstall it
correctly.
DECLARATION OF
CONFORMITY
We,
Positec Germany GmbH
Grüner Weg 10, 50825 Cologne, Germany
Declare that the product,
Description Worx Jigsaw
Type WX477 WX477.1 WX478 WX478.1
WX479 (460-479-designation of machinery,
representative of Jig Saw)
Function Sawing various materials
Complies with the following directives,
2006/42/EC
2014/30/EU
2011/65/EU&(EU)2015/863
Standards conform to:
EN 62841-1
EN 62841-2-11
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
The person authorized to compile the technical file,
Name Marcel Filz
Address Positec Germany GmbH Grüner Weg
10, 50825 Cologne, Germany
2021/4/15
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China
