Jigsaw EN
12
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration and noise accessories.
Plan your work schedule to spread any high
vibration tool use across a number of days.
ACCESSORIES
WX477
WX477.1
WX478
WX478.1
WX479
Hex key 1 1 1
Metal cutting
blade
111
Wood cutting
blade
111
Aluminum
cutting blade
111
Parallel guide / 1 1
Vacuum
adaptor
/11
We recommend that you purchase your
accessories from the same store that sold you the
tool. Refer to the accessory packaging for further
details. Store personnel can assist you and offer
advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for sawing wood, plastic,
metal and building materials while resting firmly
on the workpiece. It is suitable for straight and
curved cuts with mitre angles to 45°. The saw blade
recommendations are to be observed.
ASSEMBLY AND OPERATION
Action Figure
Blade Installation
See Fig. A1
Blade Removing See Fig. A2
Variable Speed Control (Only
for WX478 WX478.1 WX479)
See Fig. B
Pendulum Function See Fig. C
ON/OFF Switch See Fig. D
Lock-On Button See Fig. D
Straight Cut and Curve Cut See Fig. E1,E2
Bevel Cut See Fig. F,G
Plunge Cut See Fig. H
Parallel Guide (Only for WX478
WX478.1 WX479)
See Fig. I1,I2
Blade Storage (Only for WX478
WX478.1 WX479)
See Fig. J
Vacuum Adaptor (Only for
WX478 WX478.1 WX479)
See Fig. K
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional lubrication
or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls
free of dust. Occasionally you may see sparks
through the ventilation slots. This is normal and will
not damage your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
