5COOLIUS A50 / Y50
1.1 Flow diagram - SPARE PARTS LIST
N° DESCRIPTION CODE
01 HP SERVICE COUPLING (A50 R134a) 0605115006
HP SERVICE COUPLING (Y50 / Y50A R1234yf) 0605512006
02 LP SERVICE COUPLING (A50 R134a) 0605115001
LP SERVICE COUPLING (Y50 / Y50A R1234yf) 0605512001
03 HP GAUGE (A50 / Y50 / Y50A R134a/R1234yf) 0710175085
04 LP GAUGE (A50 / Y50 / Y50A R134a/R1234yf) 0710145085
05 3 m SERVICE HOSE HP (A50 R134a) 0603015030
3 m SERVICE HOSE HP (Y50 / Y50A R1234yf) 0603019030
06 3 m SERVICE HOSE LP (A50 R134a) 0603010030
3 m SERVICE HOSE LP (Y50 / Y50A R1234yf) 0603013030
07 MANIFOLD (A50 R134a) 0510006008
MANIFOLD (Y50 / Y50A R1234yf) 0510006013
08 ELECTRONIC PRESSURE TRANSDUCER 0712350007
09 INTERNAL VESSEL PRESSURE GAUGE 0710040250
10 VACUUM PUMP 128L 0420023137
11 CHARGE HOSE (A50 R134a) 0603055361
CHARGE HOSE 7/16 UNF O-RING (Y50 / Y50A R1234yf) 0603511041
12 RECOVERY HOSE W/VALVE + ADD.CHECK VALVE (A50 R134a) 0613010401
RECOVERY HOSE 7/16 UNF O-RING (Y50 / Y50A R1234yf) 0603400235
20 COMPRESSOR 5/8 HP 0416190027
21 CAPILLARY 0602099420
22 COMPRESSOR COPPER PIPE 0602005020
23 OIL DISTILLER GROUP (A50 R134a) 0611013054
OIL DISTILLER GROUP (Y50 / Y50A R1234yf) 0611013057
24 MAIN FILTER 0607350344
25 HIGH PRESSURE SWITCH 0703014019
26 COMPRESSOR FAN (D172 230V - LONG CABLE FAN) 0408172053
27
ELECTRIC VALVE GROUP “1A”
(LP / XP / RF / A1* / A2 / EO / EO2 / A3 / GA** / BP** / E3**)
0500142050
28 CHECK VALVE - RECOVERY (G1/8 FM) 0501086063
29 CHECK VALVE - OIL DISTILLER (7/16UNF O-Ring MM) 0501071605
30 LIQUID RECEIVER 20L GROUP (A50 R134a) 0612020051
LIQUID RECEIVER 20L GROUP (Y50 / Y50A R1234yf) 0612020059
31 HEAT BELT 0404550058
32 OVERPRESSURE VALVE 0503016045
33 SAFETY VALVE (A50 R134a) 0503144020
SAFETY VALVE (Y50 / Y50A R1234yf) 0503144024
34 INTERNAL VESSEL ADAPTER GROUP (A50 R134a) 0612510009
INTERNAL VESSEL ADAPTER GROUP (Y50 / Y50A R1234yf) 0612511050
38 MANIFOLD FOR PRESSURE TEST 0512200005
39 CHECK VALVE - NITROGEN TEST (G1/8 FF) 0501086062
40 NEW OIL BOTTLE 250 ml (YELLOW PIPE) 0819015250
41 UV TRACER BOTTLE 100 ml 0819015100
