8 COOLIUS A50 / Y50
2.1 Electric diagram - SPARE PARTS LIST
N° DESCRIPTION CODE
01 MAIN SWITCH 0404230022
02 EMERGENCY SAFETY SWITCH (R1234yf ONLY) 0414020005
03 MAIN FAN (D172 230V - LONG CABLE FAN) 0408172053
04 COMPRESSOR FAN (D172 230V - LONG CABLE FAN) 0408172053
05 COMPRESSOR 5/8 HP 0416190027
06 VACUUM PUMP 128L 0420023137
07 HEAT BELT 0404550058
8a
ELECTRIC VALVE GROUP “1A”
(LP / XP / RF / A1* / A2 / EO / EO2 / A3 / GA** / BP** / E3**)
0500142050
PISTON FOR “1A” ELECTRIC VALVE
(LP / XP / RF / A1* / A2 / EO / EO2 / A3 / GA** / BP** / E3**)
0500142150
8b
ELECTRIC VALVE GROUP “1B”
(NO / UV / HO / VP)
0500142075
PISTON FOR “1B” ELECTRIC VALVE
(NO / UV / HO / VP)
0500142175
10 HIGH PRESSURE SWITCH 0703014019
(*) Applies to R1234yf models only (Y50 / Y50A).
(**) Applies to Y50A only.
