Wow SparkMaker User Manual

108
❷
The long-span cantilever position
,
the lowest point position of the layer
,
the position that needs to be
strengthened and so on in the model le are all added with the right thickness
,
the right number of supports and
the correct bottom valve.
❸
The slice parameters such as the layer thickness
,
exposure time
,
and lift speed of the print le are set correctly.
❹
The slice le is completely saved in the SD card
,
the bottom surface is completely attached to the ground
,
and
there is no fault in the middle.
❺
If you use the knob to control the printer
,
you need to name the print file as
"print.wow"(for
SparkMaker
version)or "print.fhd" (for
SparkMaker FHD
version)
and save it to the SD card.
©How to check if the LCD screen and light board are working properly?
First remove the tank and printing platform
,
then insert the SD card with the printed file
,
press the knob to start
printing
,
then wait for the light board to light up
,
the LCD screen displays the image
,
observe whether the image is
normal
,
the light on the light board Whether the beads are normally lit.
©Problems about the loss of LCD screen and light board.
The
SparkMaker
SLA 3D printer uses a liquid crystal screen as a graphic display component and uses a UV
backlight as the light for curing the resin. Because the LCD screen is exposed to UV light
,
it will be damaged under
long-term use. It has a life of
2-3 months
under frequent use. When the LCD screen has black spots and the
light transmittance is poor
,
the exposure time is obviously longer or the graphics or the like cannot be displayed
normally
,
the LCD screen should be replaced in time. The UV LED board will also wear out during long-term
exposure. It can be kept for
2-3 months
without signicant light energy loss under frequent use. When the light
intensity is obviously weakened
,
the exposure time is obviously longer or there are some UV LEDs don't light or
weak
,
the light board should be replaced in time.
©Do I need to leveling the platform before every print?
The
SparkMaker
SLA 3D printer uses a high-precision photoelectric switch with high repeatability
,
so after
proper leveling
,
if you do not adjust the Z axis
,
do not loosen the four screws on both sides of the platform
,
and do
not reinstall the resin tank
,
normally you don't need to leveling the platform again.
FAQ
Basic operational concept
