Würth TIG 200 pulse User Manual

25
Spare Parts List
No.
Description Unit QTY
1
Handle
pcs
1
2
Shell
pcs
1
3
Main PCB Board
pcs
1
4
Pulse arc run-on pcb board
pcs
1
5
Spacer
pcs
4
6
Heat sink connecting plate
pcs
2
7
Small pressing plate
pcs
2
8
Fast recovery diode
pcs
6
9
Heat sink
pcs
1
10
Mouting plate
pcs
1
11
Front panel
pcs
1
12
Out put fix plate
pcs
1
13
Potentiometer knob
pcs
1
14
Plastic panel
pcs
1
15
Earth cable
pcs
1
16
Tig torch
pcs
1
17
Quick connector
pcs
2
18
Torch switch
pcs
1
19
Argon connector
pcs
1
20
Machine feet
pcs
4
21
Bottom plate
pcs
1
22
Coupling transformer
pcs
1
23
Torch switch isolation plate
pcs
1
24
Rectifier PCB board
pcs
1
25
Hall
pcs
1
26
Power PCB board
pcs
1
27
Heat sink fix holder
pcs
2
28
Insulation plate for Transformer rectifier PCB board
pcs
1
29
IGBT heat sink
pcs
1
30
IGBT
pcs
4
31
Fan cover
pcs
1
32
Fan
pcs
1
33
Insulation plate of Main PCB board
pcs
1
34
Plastic panel 2
pcs
1
35
Tension disc
pcs
2
36
Rocker switch
pcs
1
37
Gas valve
pcs
1
38
Connecting screw rod
pcs
1
39
Forced fixing cable head
pcs
1
40
Power line
pcs
1
Note: above table spare parts list is just for reference.
