WYBOT C1 Pro - Product Overview; Product External Overview; Product Internal Overview; Packing List

01 02
Packing List
WYBOT C1 PRO/MAX(OS7010/OS7010 Max) AT A GLANCE
Filter Basket
Store collected dirt and debris, need to
be washed after each use.
j
Sealed Part
Important components are sealed there.
For your safety, do not try to disassemble it
without authorization.
k
Product External Overview
Product Internal Overview
Do not operate the device when the top cover or scrubbing brushes are broken.
If there is any liquid leakage from the sealing part, stop charging or running
the device.
d
f
e
g
b
c
a
h
j
Handle
Remove and transport the device with it
on/off Button
Turn on/ turn off the device
a
b
d
LED Indicator
Different light colors to indicate device status
f
Pump
Suck debris and pump out water through
the window
c
Cleaning Mode Indicator
The chosen cleaning mode will be shown here
g
Top Cover Open Handle
Open the top cover to take out filter basket
Charging Port
Connect the charging cable
h
j
Track
Enhance device’s capability in climbing walls
and various obstacles
e
Scrubbing Brush
Knock loose all dirt and roll them all into the
device
Device x 1
Filter Basket x 1
Charger x 1
Quick Start Guide x 1
Hook x 1
Floating Parts
j
k
User Manual x 1
