Xantrex DR1512E User Manual

21
2.0 INSTALLATION
©2000 Xantrex Technology Inc.
12 V
12 V
3597-F00-D30
12 V
12 V
12 V 12 V 12 V 12 V
+ –
48 V INVERTER
(Total battery capacity = 100 Ah)
+ – + – + – + –
+ + – + – + – –
Cross-tie cable
(not required)
Cross-tie cable
(not required)
Cross-tie cable
(not required)
Cross-tie cable
(not required)
Cross-tie cable
(not required)
Cross-tie cable
(not required)
Fuse Block
Disconnect
12 V
12 V
3597-F00-D34
12 V 12 V
+ – + –
+ +–
Cross-tie cable
(not required)
Cross-tie cable
(not required)
Fuse Block
Disconnect
+ –
24 V INVERTER
(Total battery capacity = 100 Ah)
–
Figure 18
12 Volt Battery WiringSeries/Parallel Configuration
(with optional cross-tie wiring)
Wiring (continued)
Cross-Tying Series/Parallel Configurations (continued)
