40 Freedom SW 3000 Owner’s Guide
Configuration
Cfg AC Limits (Configure AC Limits)
Cfg AC Limits is a sub-menu. If selected, a list of sub-menu items appear.
For more information on this sub menu, Configure AC Limits, see page 41.
# Chg Stages
Full name Number of charge stages
Configurable setting These settings let you adjust your charger stages to
either two-stage charging or three-stage charging. The default setting for
# Chg Stages is 3Stage. (“Battery Charging Reference” on page 55.)
Eqz Volts
Full name Equalization voltage
Configurable setting This setting lets you set the desired equalization
voltage. This menu is displayed only if charger equalization is enabled.
Select a setting based on the battery manufacturer’s recommendation. For
more information, see “Battery Charging Reference” on page 55.
You can adjust Eqz Volts settings as follows:
Force Charge
Configurable setting This setting forces the charger to be enabled (On)
whenever you have re qualified AC. The default setting for Force Charge is
On (enabled).
When to use Turn Force Charge to On if you want to automatically start
charging whenever you connect to a qualified AC input, regardless of
whether the Charger is Enabled or Disabled.
Turn Force Charge to Off if you want charging to be determined only by
whether the Charger is Enabled or Disabled.
Outcome If Force Charge is turned to On, the charger starts whenever
you have qualified AC.
# Chg Stages [3Stage]
Eqz Volts [15.5V]
Range of values Increment Default
13.5 to 15.5 VDC 0.1 volts 15.5 VDC
Force Charge [On]
