Basic Installation Procedures
16 Freedom X Owner's Guide
Basic Installation Procedures
This section provides sample installation information as a guide
for your installation. For your convenience, the overall procedure
is divided into these main steps:
Step 1: Designing the Installation 17
Step 2: Choosing a Location for the Unit 23
Step 3: Mounting the Unit 24
Step 4: Connecting the AC Input Wires 26
Step 5: Connecting AC Output to an Existing AC Circuit 31
Step 6: Connecting the DC Cables 33
Step 7: Connecting to Port(s) on the Freedom X 39
Step 8: Testing Your Installation 39
NOTE: For marine applications, see additional installation
instructions on page 41.
