975-0526-01-02 49

Replacing the DC Output Fuse

Fuse Replacement Ratings

RISK OF EQUIPMENT DAMAGE

For continued protection, replace only with Littelfuse

type 257 (or

equivalent) with ratings as shown below.

Failure to follow these instructions can damage the unit and/or

damage other equipment.

Model Amperage Voltage

TC2012 30 A (green) 32 Vdc

TC4012 2×30 A (green) 32 Vdc

TC6012 3×30 A (green) 32 Vdc

TC1024 30 A (green) 32 Vdc

TC2024 15 A (blue) 32 Vdc

TC3024 40 A (amber) 32 Vdc

TC2 204060 Series BattChg Owners Guide.book Page 49 Friday, July 8, 2011 11:44 AM

Questions and Answers:

Need help?

Do you have a question about the Xantrex truecharge 2 series and is the answer not in the manual?

General

Input Voltage	90-265 VAC
Input Frequency	47-63 Hz
Number of Banks	3
Dimensions	Varies by model
Weight	Varies by model
Output Voltage	12 VDC or 24 VDC
Output Current	20A, 40A, or 60A
Battery Types	Flooded, Gel, AGM
Charging Stages	3-stage (Bulk, Absorption, Float)
Protection Features	Overvoltage, Overcurrent, Short Circuit, Reverse Polarity, Over Temperature
Operating Temperature	-20°C to +50°C
