Alternate System Configurations
C–2 975-0239-01-01
This manual for use by qualified personnel only
DC Grounding for Single-Inverter Systems
See Table 2-4, “Torque Values for AC Wiring (AC Terminals and Ground Bar),” on
page 10.
See Table 2-5, “Torque Values for the Chassis Ground Lug,” on page 10.
See Table 2-6, “Torque Values for the Inverter Battery Terminals,” on page 10.
Figure C-1
DC Grounding for an Inverter only
This illustrates an example only. Actual
ground requirements may vary.
To Next Page
